Product Specification
Fiberglass geogrid is an excellent geosynthetic material used for road surface reinforcement, old road reinforcement, roadbed reinforcement and soft soil foundation.
The glass fiber geogrid is a semi-rigid product made of high-strength alkali-free glass fiber through the international advanced warp knitting process and made into a mesh substrate and surface coating.
Performance/Model | EGA40-40 | EGA50-50 | EGA100-100 | EGA120-120 | |
Breaking strengthkn/m | Vertical | ≥40 | ≥50 | ≥100 | ≥120 |
Broadwise | ≥40 | ≥50 | ≥100 | ≥120 | |
Elongation at break% | Vertical | ≤4 | |||
Broadwise | ≤4 | ||||
Grid size mm×mm | 12.7×12.7 25.4×25.4 40×40 | ||||
Width m | 1~6 |
Fiberglass Geogrid Usage:
- For old asphalt concrete pavement, reinforce the asphalt surface layer to prevent and control diseases.
- The cement concrete pavement is rebuilt into a composite pavement, and the reflection cracks caused by plate shrinkage are suppressed.
- Road extension and improvement projects to prevent cracks caused by the junction of old and new and uneven settlement.
- Reinforcement treatment of soft soil foundation is conducive to the consolidation of soft soil, effectively inhibits settlement, and uniform stress distribution, and enhances the overall strength of the roadbed.
- The semi-rigid base of the new road produces shrinkage cracks, and the reinforcement is reinforced to prevent pavement cracks caused by the reflection of the foundation cracks.
![Fiberglass Geogrid Case](https://i0.wp.com/shelterrc.com/wp-content/uploads/2023/07/Fiberglass-Geogrid-Case.jpg?resize=600%2C400&ssl=1)
![Fiberglass Geogrid](https://i0.wp.com/shelterrc.com/wp-content/uploads/2023/07/Fiberglass-Geogrid.jpg?resize=600%2C400&ssl=1)
Fiberglass Geogrid Applications:
- Road construction
- Retaining walls
- Embankments and slopes
- Mining and landfills
- Pipeline and utility trenches
